New filter dimensions: this high-end modular filter system cleans large ponds up to 530 m³ (100 m³ for koi ponds). Convenient control functions as well as an intelligent automatic cleaning function guarantee you optimal comfort: Adjust...
Lire la suite >>
Lire la suite >>
SKU 73365
Description du produit :
New filter dimensions: this high-end modular filter system cleans large ponds up to 530 m³ (100 m³ for koi ponds). Convenient control functions as well as an intelligent automatic cleaning function guarantee you optimal comfort: Adjust all settings from the app thanks to a simple connection to the Easy Garden Control (EGC) system Perfectly suited for owners of large, very demanding ponds , XL-Moving Beds offer excellent degradation rates of ammonium, ammonia, nitrites and nitrates.
- Modern modular filter system for professional water quality in minimal volume
- Proven professional technology with over 3 years of development
- Excellent degradation rates of ammonium, ammonia, nitrites and nitrates
- Conveniently adjust all settings from the app thanks to the connection options to the Easy Garden Control (EGC) system. Retrofitting of existing installations possible via upgrade kit available separately
- Highly efficient decomposition of pollutants and nutrients thanks to professional filter media used in a turbulent mixing process (Moving Bed)
- Excellent filtration capacity with intelligent control functions
- Intelligent self-cleaning function (drum filter module)
- Flexible adaptation of the filter system to individual needs (Individual module)
- Innovative and reliable product "Made in Germany*" (*except pump)
- Requirements: An InScenio EGC Controller Home/Cloud, an InScenio FM Master EGC Home/Cloud, an InScenio FM Master WLAN EGC or an InScenio FM Master WLAN Version 2.0 or newer is required to operate the EGC functions.
TECHNICAL DATA
| Dimensions (LxWxH) | mm | 1330x875x820 |
|---|---|---|
| Nominal voltage | 230V / 50Hz | |
| Energy consumption | W | 5 |
| Cleaning consumption | W | 1600 |
| Cable length | m | 5.00 + 5.00 |
| Net weight | kg | 125.00 |
| Warranty (+ Extended Warranty) | Year | 2+1 |
| Control unit | Microcontroller | |
| Temperature indicator | Digital | |
| Separation of coarse impurities | µm | 60 |
| Number of nozzles / rinsing flow | 8 x 2.5 l/min | |
| Rinse pump | 7 bar | |
| Automatic rinsing | Manual, Sensor, Time Lapse | |
| Number of screening elements | PCE | 16 |
| Filter suction area | cm 2 | 6900 |
| Material | Thermoset fiberglass plastic/stainless steel | |
| Number of entries | PCE | 5 |
| Inlet fittings | 3 x 2" / 2 x DN 110 | |
| Number of outputs | PCE | 2 |
| Outlet fittings | 180mm | |
| Dirt outlet connections | DN 75 | |
| Rinsing chute connection | DN 110 | |
| Connection to | Bitron Premium, ProfiCl. First. XL Individual module pump, ProfiClear Premium XL Moving Bed | |
| Liters per hour min. | l/h | 25000 |
| Liters per hour max. | l/h | 50000 |
| Installation height above water level | cm | 52.0 |
| type of use | Pumping system | |
| Others | Waste outlet with valve included |
